| Motherboard |
|
| CPU |
- Single Intelｮ Pentiumｮ 4 Processor
of up to 3.06GHz
|
| Memory |
- Up to 2GB of DDR333/266/200
memory
|
| Front Side
BUS |
|
| Chipset |
|
| I/O Expansion |
- 1 32-bit, 33MHz half-length PCI
|
| Onboard I/O Devices |
- Intel EXTREME graphics accelerator
on-chip
- Dual Ultra DMA/100
- Burst data transfer rate
supports UDMA Mode 5, PIO Mode 4, ATAPI
- 2 Intel
82540EM gigabit LAN controller
- 2 USB 2.0
- PS/2 keyboard and PS/2 mouse
connectors
- 2 fast UART 16550 compatible
serial ports
- 1 ECP/EPP parallel port
- 1
Infrared port
- 1 floppy port
|
| BIOS |
- 4Mb flash BIOS
- BIOS rescue recovery feature
- Hardware BIOS virus
protection
- ACPI/APM power management
PnP
- PXE headless support
|
|
| Chassis |
|
| Form
Factor |
- Mini-1U
Rackmount
- Rackmount Kit optional
|
| Power
Supply |
- 200W power supply (PWS-0020)
- Auto-switching 100/240 AC
power
|
| SCA
Subsystem |
|
| Cooling
Subsystem |
|
| External
Drive Bays |
- 1 Slim 1.44MB Floppy drive
- 1 Slim CD-ROM
|
| Other
Features |
- ACPI/APM power management
- Onboard AOL2 (Alert-on-LAN2)
controller chip (optional)
- PC'99 color-coded I/O
connectors
- WOL (wake-on-LAN) connector
- Internal/external modem
wake-up
- Control of power-on mode for
recovery from AC power loss
- Chassis intrusion detection
|
| PC
Health Monitoring |
- 4 Onboard voltage monitors
for CPU
- 4 Fan status
- Environmental temperature
monitor and control
- Chassis and CPU overheat
alarm, LED indication and control
- System resource alert
- Supermicro System Management
utility
|
| Dimensions |
- Width: 16.7 in.
- Height: 1.7 in.
- Depth: 14 in.
- Weight: 21
lb. (Gross)
|
|
|
|
